Create cni plugin from scratch with go part 3
This is will be the last part of Create cni plugin from scratch with go.
In my last post i’m was asking how to automate the adding ip route,firewall,cni config into kube deployment right?
Now let’ me answer it.
but before that let me apply my cni deployment
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
root@ubuntu-nested-1:~# kubectl get pods -o wide -A
NAMESPACE NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
default alpine-deployment-6d7b74c778-wm9lg 0/1 Pending 0 36m <none> <none> <none> <none>
default gcc-deployment-864cc9b57b-w94bz 0/1 Unknown 231 23d <none> ubuntu-nested-3 <none> <none>
default golang-deployment-84f5dfdc6f-bhjjm 0/1 Unknown 3 5d18h <none> ubuntu-nested-3 <none> <none>
default kano-deployment-6c6c494846-rsdcj 0/2 Unknown 86 34d <none> ubuntu-nested-3 <none> <none>
default lon-deployment-6bfc6dcfb-h26z2 0/2 Unknown 68 23d <none> ubuntu-nested-3 <none> <none>
ingress-nginx ingress-nginx-controller-85786f6c49-zhvk7 0/1 Error 6 6d4h <none> ubuntu-nested-2 <none> <none>
kube-system coredns-74ff55c5b-5z5gh 0/1 Unknown 5 6d4h <none> ubuntu-nested-3 <none> <none>
kube-system coredns-74ff55c5b-hmnt8 0/1 Unknown 2 6d4h <none> ubuntu-nested-2 <none> <none>
kube-system etcd-ubuntu-nested-1 1/1 Running 77 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system kube-apiserver-ubuntu-nested-1 1/1 Running 75 59d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system kube-controller-manager-ubuntu-nested-1 1/1 Running 149 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system kube-proxy-6jlfh 1/1 Running 77 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system kube-proxy-764tr 1/1 Running 76 66d 200.0.0.20 ubuntu-nested-2 <none> <none>
kube-system kube-proxy-w9s96 1/1 Running 73 66d 200.0.0.30 ubuntu-nested-3 <none> <none>
kube-system kube-scheduler-ubuntu-nested-1 1/1 Running 149 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system metrics-server-56ccf9dff5-sl6z2 0/1 Error 7 6d4h <none> ubuntu-nested-2 <none> <none>
metallb-system controller-84645df84b-rpz2x 0/1 Error 9 6d5h <none> ubuntu-nested-2 <none> <none>
metallb-system speaker-6fhkq 1/1 Running 96 39d 200.0.0.30 ubuntu-nested-3 <none> <none>
metallb-system speaker-dvjhr 1/1 Running 103 39d 200.0.0.20 ubuntu-nested-2 <none> <none>
metallb-system speaker-kpz8z 1/1 Running 49 13d 200.0.0.10 ubuntu-nested-1 <none> <none>
root@ubuntu-nested-1:~# kubectl apply -f https://raw.githubusercontent.com/JustHumanz/Kube-dojo/CNI_Deployment/Network/CNI/humanz-cni.yml
clusterrole.rbac.authorization.k8s.io/humanz-cni created
serviceaccount/humanz-cni created
clusterrolebinding.rbac.authorization.k8s.io/humanz-cni created
daemonset.apps/humanz-cni-node created
root@ubuntu-nested-1:~# sleep 5
root@ubuntu-nested-1:~# kubectl get pods -o wide -A
NAMESPACE NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
default alpine-deployment-6d7b74c778-wm9lg 0/1 Pending 0 45m <none> <none> <none> <none>
default gcc-deployment-864cc9b57b-w94bz 1/1 Running 232 23d 100.100.2.5 ubuntu-nested-3 <none> <none>
default golang-deployment-84f5dfdc6f-bhjjm 1/1 Running 4 5d18h 100.100.2.3 ubuntu-nested-3 <none> <none>
default kano-deployment-6c6c494846-rsdcj 2/2 Running 88 34d 100.100.2.4 ubuntu-nested-3 <none> <none>
default lon-deployment-6bfc6dcfb-h26z2 2/2 Running 70 23d 100.100.2.2 ubuntu-nested-3 <none> <none>
ingress-nginx ingress-nginx-controller-85786f6c49-zhvk7 0/1 Running 7 6d4h 100.100.1.3 ubuntu-nested-2 <none> <none>
kube-system coredns-74ff55c5b-5z5gh 0/1 Running 6 6d4h 100.100.2.6 ubuntu-nested-3 <none> <none>
kube-system coredns-74ff55c5b-hmnt8 0/1 Running 3 6d4h 100.100.1.5 ubuntu-nested-2 <none> <none>
kube-system etcd-ubuntu-nested-1 1/1 Running 77 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system humanz-cni-node-4w94n 1/1 Running 0 8m20s 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system humanz-cni-node-p78tm 1/1 Running 0 8m20s 200.0.0.30 ubuntu-nested-3 <none> <none>
kube-system humanz-cni-node-ztvzk 1/1 Running 0 8m20s 200.0.0.20 ubuntu-nested-2 <none> <none>
kube-system kube-apiserver-ubuntu-nested-1 1/1 Running 75 59d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system kube-controller-manager-ubuntu-nested-1 1/1 Running 149 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system kube-proxy-6jlfh 1/1 Running 77 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system kube-proxy-764tr 1/1 Running 76 66d 200.0.0.20 ubuntu-nested-2 <none> <none>
kube-system kube-proxy-w9s96 1/1 Running 73 66d 200.0.0.30 ubuntu-nested-3 <none> <none>
kube-system kube-scheduler-ubuntu-nested-1 1/1 Running 149 66d 200.0.0.10 ubuntu-nested-1 <none> <none>
kube-system metrics-server-56ccf9dff5-sl6z2 0/1 Running 8 6d4h 100.100.1.2 ubuntu-nested-2 <none> <none>
metallb-system controller-84645df84b-rpz2x 0/1 Running 10 6d5h 100.100.1.4 ubuntu-nested-2 <none> <none>
metallb-system speaker-6fhkq 1/1 Running 96 39d 200.0.0.30 ubuntu-nested-3 <none> <none>
metallb-system speaker-dvjhr 1/1 Running 103 39d 200.0.0.20 ubuntu-nested-2 <none> <none>
metallb-system speaker-kpz8z 1/1 Running 49 13d 200.0.0.10 ubuntu-nested-1 <none> <none>
root@ubuntu-nested-1:~# ip route
default via 192.168.122.1 dev enp1s0 proto dhcp src 192.168.122.173 metric 100
100.100.1.0/24 via 200.0.0.20 dev enp8s0
100.100.2.0/24 via 200.0.0.30 dev enp8s0
172.17.0.0/16 dev docker0 proto kernel scope link src 172.17.0.1 linkdown
192.168.122.0/24 dev enp1s0 proto kernel scope link src 192.168.122.173
192.168.122.1 dev enp1s0 proto dhcp scope link src 192.168.122.173 metric 100
192.168.123.0/24 dev virbr0 proto kernel scope link src 192.168.123.1 linkdown
200.0.0.0/24 dev enp8s0 proto kernel scope link src 200.0.0.10
root@ubuntu-nested-1:~# iptables -t nat -nvL | grep 100.100.0.0/24
0 0 MASQUERADE all -- * enp1s0 100.100.0.0/24 0.0.0.0/0 /* Nat from pods to outside */
root@ubuntu-nested-1:~#
Ok now all pods was ready and already get the ip address,let’s me explain the deployment
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
name: humanz-cni
labels:
app: humanz-cni
rules:
- apiGroups: [""]
resources: ["pods", "nodes"]
verbs: ["get", "list", "watch"]
---
apiVersion: v1
kind: ServiceAccount
metadata:
name: humanz-cni
namespace: kube-system
labels:
app: humanz-cni
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
name: humanz-cni
labels:
app: humanz-cni
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: humanz-cni
subjects:
- kind: ServiceAccount
name: humanz-cni
namespace: kube-system
---
In here i’m just creating rbac for my cni agent,i’m need privilage to get nodes & pods info also watch it
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
# This manifest used to installs the humanz-cni plugin and config on each master and worker node
# in a Kubernetes cluster with install-humanz-cni.sh script in the container.
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: humanz-cni-node
namespace: kube-system
labels:
app: humanz-cni
spec:
selector:
matchLabels:
app: humanz-cni
updateStrategy:
type: RollingUpdate
rollingUpdate:
maxUnavailable: 1
template:
metadata:
labels:
app: humanz-cni
annotations:
# Mark this pod as a critical add-on to ensure it gets
# priority scheduling and that its resources are reserved
# if it ever gets evicted.
scheduler.alpha.kubernetes.io/critical-pod: ''
spec:
nodeSelector:
# The humanz-cni currently only works on linux node.
beta.kubernetes.io/os: linux
hostNetwork: true
tolerations:
# Make sure humanz-cni-node gets scheduled on all nodes.
- effect: NoSchedule
operator: Exists
# Mark the pod as a critical add-on for rescheduling.
- key: CriticalAddonsOnly
operator: Exists
- effect: NoExecute
operator: Exists
serviceAccountName: humanz-cni
containers:
# This container installs the humanz-cni binary
# and CNI network config file on each node.
- name: install-humanz-cni
image: docker.io/justhumanz/humanz-cni:latest
imagePullPolicy: IfNotPresent
env:
# Pod name
- name: POD_NAME
valueFrom:
fieldRef:
fieldPath: metadata.name
# Node name
- name: NODE_NAME
valueFrom:
fieldRef:
fieldPath: spec.nodeName
volumeMounts:
- mountPath: /app/bin
name: cni-bin-dir
- mountPath: /app/config
name: cni-net-dir
securityContext:
capabilities:
add:
- NET_ADMIN
volumes:
# CNI bininary and configuration directories
- name: cni-bin-dir
hostPath:
path: /opt/cni/bin
- name: cni-net-dir
hostPath:
path: /etc/cni/net.d
Like others cni,i’m was setting the pods into daemon set so all nodes will spwan my cni and ofc i’m attach the pods with rbac
In that deployment it’s will pull docker.io/justhumanz/humanz-cni:latest image,now let see the dockerfile from this image
1
2
3
4
5
6
7
8
9
10
from golang:alpine
RUN apk update && apk add --no-cache iptables
COPY . /app
RUN mkdir config
WORKDIR /app/cmd/humanz-cni
RUN go build -o /humanz-cni .
RUN chmod 755 /humanz-cni
WORKDIR /app/cmd/humanz-cni-agent
RUN go build -o /humanz-cni-agent .
ENTRYPOINT /humanz-cni-agent
Now from that deployemnt we know if inside humanz-cni image will create dir /app/config and if we see at daemonset deployment /app/config will mount it into /etc/cni/net.d, anyway let’s continue
The secound things is the humanz-cni image will build two binary, one is /humanz-cni and another one is /humanz-cni-agent, also /humanz-cni-agent will be the ENTRYPOINT, now let’s see what is humanz-cni-agent
let me explain humanz-cni-agent main.go
1
2
3
4
5
const (
CNI_CONFIG_PATH = "/app/config/10-humanz-cni-plugin.conf"
CNI_BIN_PATH_SRC = "/humanz-cni"
CNI_BIN_PATH_DST = "/app/bin/humanz-cni"
)
first let’s declare the constanta of config file/binary path
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
NodeHostName := os.Getenv("HOSTNAME")
log.WithFields(log.Fields{
"Hostname": NodeHostName,
}).Info("Init CNI")
config, err := rest.InClusterConfig()
if err != nil {
log.Fatal(err)
}
clientset, err := kubernetes.NewForConfig(config)
if err != nil {
log.Fatal(err)
}
nodeList, err := clientset.CoreV1().Nodes().List(context.Background(), v1.ListOptions{})
if err != nil {
log.Fatal(err)
}
The first thing is to get node hostname by env,after that i’m need to connect into kube api through RBAC and get the node list
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
HostPodCIDR := ""
for _, Node := range nodeList.Items {
if Node.Name != NodeHostName {
//Do ip route
PodCIDR := Node.Spec.PodCIDR
NodeIP := func() string {
for _, v := range Node.Status.Addresses {
if v.Type == "InternalIP" {
return v.Address
}
}
return ""
}()
err := iface.AddNewRoute(PodCIDR, NodeIP)
if err != nil {
log.Panic(err)
}
} else {
HostPodCIDR = Node.Spec.PodCIDR
}
}
After that i’m was find the Host CIDR from kube-api and i’m also add the ip route from ‘this host to another host’
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
myCni := db.Humanz_CNI{
CniVersion: "0.3.1",
Name: "humanz-cni",
Type: "humanz-cni",
Bridge: "humanz-cni0",
Subnet: HostPodCIDR,
}
log.WithFields(log.Fields{
"Hostname": NodeHostName,
"Path": CNI_CONFIG_PATH,
}).Info("Dump cni plugin config")
file, _ := json.MarshalIndent(myCni, "", " ")
err = ioutil.WriteFile(CNI_CONFIG_PATH, file, 0755)
if err != nil {
log.Error(err)
}
In here i’m was dump the cni config file,myCni variable was cni config file in json format and i’m dump it into CNI_CONFIG_PATH which is in /app/config/10-humanz-cni-plugin.conf and don’t forget if /app/config was mounting into /etc/cni/net.d in host level, in simple way it’s will dump the cni config into /etc/cni/net.d/10-humanz-cni-plugin.conf
1
2
3
4
5
6
7
8
9
10
log.WithFields(log.Fields{
"src path": CNI_BIN_PATH_SRC,
"dst path": CNI_BIN_PATH_DST,
}).Info("Copy cni bin")
cmd := exec.Command("mv", CNI_BIN_PATH_SRC, CNI_BIN_PATH_DST)
err = cmd.Run()
if err != nil {
log.Fatal(err)
}
Remember if i’m was build two binary? yes now i’m moveing the /humanz-cni into /app/bin/humanz-cni don’t forget if i’m also mount /app/bin into /opt/cni/bin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
tab, err := iptables.New()
if err != nil {
log.Error(err)
}
err = tab.AppendUnique("filter", "FORWARD", "-s", HostPodCIDR, "-j", "ACCEPT", "-m", "comment", "--comment", "ACCEPT src pods network")
if err != nil {
log.Error(err)
}
err = tab.AppendUnique("filter", "FORWARD", "-d", HostPodCIDR, "-j", "ACCEPT", "-m", "comment", "--comment", "ACCEPT dst pods network")
if err != nil {
log.Error(err)
}
NatIface := iface.DetectOutsideNat()
if NatIface == "" {
log.Warn("Nat to outside network can't be found on all interface,skip the nat")
} else {
err = tab.AppendUnique("nat", "POSTROUTING", "-s", HostPodCIDR, "-o", NatIface, "-j", "MASQUERADE", "-m", "comment", "--comment", "Nat from pods to outside")
if err != nil {
log.Error(err)
}
}
And yes, don’t forget about iptables
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
knodeList := make(map[string]bool)
for _, v := range nodeList.Items {
knodeList[v.Name] = true
}
NodesWatch, err := clientset.CoreV1().Nodes().Watch(context.TODO(), v1.ListOptions{})
if err != nil {
log.Fatal(err)
}
for NodesEvent := range NodesWatch.ResultChan() {
Node := NodesEvent.Object.(*k8sv1.Node)
if !knodeList[Node.Name] {
newNode, err := clientset.CoreV1().Nodes().Get(context.TODO(), Node.Name, v1.GetOptions{})
if err != nil {
log.Fatal(err)
}
PodCIDR := newNode.Spec.PodCIDR
NodeIP := func() string {
for _, v := range newNode.Status.Addresses {
if v.Type == "InternalIP" {
return v.Address
}
}
return ""
}()
log.WithFields(log.Fields{
"NodeName": Node.Name,
"PodsCIDR": PodCIDR,
"NodeIP": NodeIP,
}).Info("New node join")
//Add ip route to new node
err = iface.AddNewRoute(PodCIDR, NodeIP)
if err != nil {
log.Fatal(err)
}
knodeList[Node.Name] = true
}
}
os.Exit(0)
And here was the last part, in here i’m just creating node watcher so if new node was joining the cluster humanz-cni-agent will add the ip route automatically.
And now all was fully automatic,no more set ip route or setup nat in each nodes.
This post is licensed under CC BY 4.0 by the author.
Comments powered by Disqus.
